Self-Host WireGuard VPN on Your VPS with wg-easy

Running your own VPN gives you full control over your traffic — no third-party logging, no bandwidth limits, and a private tunnel you can share with your devices or team. WireGuard is fast, modern, and lightweight, and wg-easy wraps it with a clean web UI for managing clients.

In this guide, we'll set up a WireGuard VPN server on a VPS using Docker, secure the admin panel behind an SSH tunnel, and create client configs via the API.

---

Prerequisites

• A VPS (Ubuntu 22.04+ recommended) with at least 512MB RAM
• A public IP address for your VPS
• SSH access to the server

---

Step 1 — Connect to Your Server

ssh root@YOUR_SERVER_IP

Replace YOUR_SERVER_IP with your VPS public IP address.

---

Step 2 — Update the System

apt update && apt upgrade -y

---

Step 3 — Install Docker

For a quick installation, use Docker's convenience script:

curl -sSL https://get.docker.com | sh

Verify the installation:

docker --version
docker compose version

If both commands return version numbers, Docker is ready.

---

Step 4 — Create the wg-easy Project

Create a dedicated directory:

mkdir -p /opt/wg-easy && cd /opt/wg-easy

Create the Docker Compose file:

nano docker-compose.yml

Paste the following configuration:

services:
  wg-easy:
    image: ghcr.io/wg-easy/wg-easy:15
    container_name: wg-easy
    environment:
      - PORT=51821
      - HOST=0.0.0.0
      - INSECURE=true
    networks:
      wg:
        ipv4_address: 10.42.42.42
        ipv6_address: fdcc:ad94:bacf:61a3::2a
    volumes:
      - etc_wireguard:/etc/wireguard
      - /lib/modules:/lib/modules:ro
    ports:
      - "51820:51820/udp"
      - "127.0.0.1:51821:51821/tcp"
    restart: unless-stopped
    cap_add:
      - NET_ADMIN
      - SYS_MODULE
    sysctls:
      - net.ipv4.ip_forward=1
      - net.ipv4.conf.all.src_valid_mark=1
      - net.ipv6.conf.all.disable_ipv6=0
      - net.ipv6.conf.all.forwarding=1
      - net.ipv6.conf.default.forwarding=1

volumes:
  etc_wireguard:

networks:
  wg:
    driver: bridge
    enable_ipv6: true
    ipam:
      driver: default
      config:
        - subnet: 10.42.42.0/24
        - subnet: fdcc:ad94:bacf:61a3::/64

What's happening here?

Setting	Purpose
51820/udp	WireGuard tunnel port (public)
127.0.0.1:51821/tcp	Web UI bound to localhost only (private)
INSECURE=true	Allows HTTP for the web panel (safe since it's localhost-only)
NET_ADMIN, SYS_MODULE	Required Linux capabilities for WireGuard
IPv6 config	Enables dual-stack VPN support

Security note: Port 51821 is intentionally bound to 127.0.0.1. The admin panel is never exposed to the internet.

---

Step 5 — Configure the Firewall

Allow only SSH and the WireGuard tunnel port:

ufw allow OpenSSH
ufw allow 51820/udp
ufw enable
ufw status

We deliberately do not open port 51821 — the web panel stays private and is only accessible via SSH tunnel.

---

Step 6 — Start the VPN Server

docker compose up -d

Verify the container is running:

docker ps

You should see a container named wg-easy with status "Up". Check the logs if needed:

docker logs wg-easy

---

Step 7 — Access the Web Panel via SSH Tunnel

Since the web UI is only available on localhost, we need to forward the port through SSH.

On your local machine, open a new terminal and run:

ssh -L 51821:localhost:51821 root@YOUR_SERVER_IP

Keep this terminal open, then navigate to:

http://localhost:51821

You'll see the wg-easy setup page. Create your admin credentials.

When prompted for the host, enter your VPS public IP (or domain if you have one). For the port, keep the default:

51820

---

Step 8 — Create Clients via the Web UI

The simplest way to add devices is through the web panel:

1. Click "+ New" in the dashboard
2. Give the client a name (e.g., my-phone, laptop-work)
3. Download the .conf file or scan the QR code with the WireGuard app

---

Step 9 — Create Clients via the API (Optional)

If you prefer automation or need to script client creation, wg-easy exposes a REST API.

Create a new client

curl -u "admin:YOUR_PASSWORD" \
  -H "Content-Type: application/json" \
  -X POST \
  -d '{"name": "user_1001", "expiresAt": null}' \
  http://127.0.0.1:51821/api/client

Example response:

{
  "success": true,
  "clientId": 12
}

Download the client config file

curl -u "admin:YOUR_PASSWORD" \
  -o user_1001.conf \
  http://127.0.0.1:51821/api/client/12/configuration

Get a QR code (for mobile devices)

curl -u "admin:YOUR_PASSWORD" \
  -o user_1001.svg \
  http://127.0.0.1:51821/api/client/12/qrcode.svg

Replace 12 with the clientId returned from the create step, and YOUR_PASSWORD with your admin password.

---

Connecting Devices

1. Install the WireGuard app on your device
2. Import the .conf file or scan the QR code
3. Toggle the connection on — you're now routing through your VPS

You can verify by checking your IP:

curl ifconfig.me

It should return your VPS IP address.

---

Troubleshooting

Container won't start?

• Check logs: docker logs wg-easy
• Ensure /lib/modules exists on the host (needed for WireGuard kernel module)

Can't connect to VPN?

• Verify port 51820/udp is open: ufw status
• Ensure the host IP in wg-easy settings matches your actual VPS public IP

Web panel not loading via tunnel?

• Make sure the SSH tunnel is active in your terminal
• Confirm the container is running: docker ps

Handshake but no traffic?

• Check that IP forwarding sysctls are applied: docker inspect wg-easy | grep -A5 Sysctls

---

Wrapping Up

You now have a self-hosted WireGuard VPN with a web dashboard — zero subscription fees, full control over your data, and client management through a clean UI or API. The SSH tunnel approach keeps the admin panel completely off the public internet without needing additional auth layers or reverse proxies.

Add devices as you need them, revoke access with one click, and sleep well knowing your traffic isn't being logged by anyone but you.
